roduct Overview
The MikroTik CCR2216-1G-12XS-2XQ is a next-generation Cloud Core Router that delivers unmatched performance for ISPs, research facilities, file hosting, and enterprises with high data demands. Powered by the AL73400 16-core 2 GHz CPU and the Marvell Prestera Aldrin2 switch-chip with L3 Hardware Offloading, it offers blazing-fast single-core performance — at least 4x faster than the previous CCR1072 Tile CPU.

Featuring 2× 100G QSFP28 cages, 12× 25G SFP28 cages, and 1× Gigabit Ethernet port, the CCR2216 is designed for seamless data-intensive networking and future-proof scalability. With 16 GB DDR4 RAM, 128 MB NAND storage, and advanced RouterOS (Level 6 license), it ensures stability and versatility for complex configurations.

Redundant power supplies, efficient cooling, and compatibility with 2× CCR2004-1G-2XS-PCIe modules make this router reliable, scalable, and ideal for mission-critical networks.

Key Features

• 100G Ready: 2× QSFP28 cages for ultra-fast 100 Gigabit connections
• 25G Backbone: 12× SFP28 cages for 25 Gigabit networking
• CPU Power: AL73400 16-core 2 GHz ARM 64-bit processor
• Memory: 16 GB DDR4 RAM
• Storage: 128 MB NAND
• Switch-Chip: Marvell Prestera Aldrin2 with L3 hardware offloading
• Cooling System: Efficient airflow design for stable operation under load
• Dual Power: Built-in dual redundant AC power supplies
• OS: RouterOS with License Level 6
• Scalable: Compatible with 2× CCR2004-1G-2XS-PCIe modules

Hardware Specifications

• Product Code: CCR2216-1G-12XS-2XQ
• CPU: AL73400, 2 GHz, ARM 64-bit
• CPU Cores: 16
• RAM: 16 GB DDR4
• Storage: 128 MB NAND
• 1G Ethernet Ports: 1
• 25G SFP28 Ports: 12
• 100G QSFP28 Ports: 2
• M.2 Slots: 2
• Switch Chip: 98DX8525
• Switch to CPU Connection: 4× 25 Gbps
• OS: RouterOS, License level 6
• Dimensions: 443 × 367 × 44 mm
• Operating Temperature: -20°C to +60°C

Powering

• Number of AC Inputs: 2 (redundant)
• AC Input Range: 100–240 V
• Power Adapter Nominal Voltage: 12 V
• Power Adapter Nominal Current: 12.5 A
• Max Power Consumption (no attachments): 80 W
• Max Power Consumption (with attachments): 121 W
